Placă de Bază Gigabyte - B760 GAMING X AX
| Specificații | |
| Dimensiuni (L x W) (cm) | 30.5 x 24.4 cm |
| Sloturi speciale | 3 x M.2 |
| Sloturi PCI-E x16 | 3 |
| Conector sursa (pini) | 1 x 8 pin 12V 1 x 24 pin |
| Interfata Serial ATA | 4 x SATA 6Gb/s |
| Conectivitate | 1 x RJ-45 6 x Audio Jacks 1 x DisplayPort 5 x USB 2.0/1.1 1 x HDMI 1 x USB tip C 2 x SMA antenna connectors 1 x USB 3.2 Gen 1 Tip-A 1 x USB 3.2 Gen 2 Tip-A |
| LAN integrat | 1 x Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Audio integrat | Realtek Audio codec |
| Slot PCI | 2 x PCI-E x16 1 x PCI-Express 4.0 16x |
| Suport ECC | Da pentru Un-buffered DIMM 1Rx8/2Rx8 |
| Suport Dualchannel | Da |
| Sloturi memorie | 4 |
| Frecventa memorie (MHz) | 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 |
| Capacitate maxima memorie RAM | 192 GB |
| Tip memorie | DDR5 |
| Socket procesor | 1 |
| Procesoare suportate | Generatia 13 si 12 Intel Core, Pentium Gold si Celeron |
| Chipset | Intel B760 |
| CPU Socket | 1700 |
| Format | ATX |
| Brand | Gigabyte |
| Tehnologii suportate | Q-Flash Q-Flash Plus GIGABYTE Control Center (GCC) |
| BIOS & memorie BIOS | 1 x 256 Mbit flash |
