Placă de Bază Gigabyte - B650M A ELITE AX ICE
| Specificații | |
| Brand | Gigabyte |
| Format | mATX |
| CPU Socket | AM5 |
| Chipset | AMD B650 |
| Procesoare suportate | AMD Ryzen 7000/8000/9000 Series |
| Tip memorie | DDR5 |
| Capacitate maxima memorie RAM | 256 GB |
| Frecventa memorie (MHz) | 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/4800/4400 MT/s |
| Suport Dualchannel | Da |
| Sloturi memorie | 4 |
| Slot PCI | PCI-Express 4.0 |
| Audio integrat | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel |
| LAN integrat | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Conectivitate | 1 x RJ-45 1 x Optical S/PDIF OUT 1 x DisplayPort 4 x USB 2.0/1.1 1 x HDMI 2 x Audio Jacks 2 x SMA antenna connectors 2 x USB 3.2 Gen 2 1 x USB 3.2 Gen 2 Tip-C 5 x USB 3.2 Gen 1 port |
| Interfata Serial ATA | 4 x SATA |
| Rata de transfer SATA | 6000 MB/s |
| Conector sursa (pini) | 1 x 24 pin ATX 1 x 8 pin 12V |
| Sloturi PCI-E x16 | 2 |
| Sloturi speciale | 2 x M.2 |
| Tehnologii suportate | Q-Flash Plus GIGABYTE Control Center (GCC) Smart Fan 6 |
| BIOS & memorie BIOS | 1 x 256 Mbit flash |
| Altele | 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Bluetooth 5.3 |
| Dimensiuni (L x W) (cm) | 24.4 x 24.4 cm |
